Output Wave Shape
Pure Sine Wave
Nominal Battery Voltage
12V DC
No Load Output Voltage
220V ±7V AC
Output Frequency
50Hz ±1Hz
No Load Battery Current
2.2A
Max. Discharging Current
53A ±1A
Battery Low Alarm
10.8V ±0.2V / Battery
Battery Low Cut OFF
10.5V ±0.2V / Battery
Recommended Nominal Mains Input
220V AC 50Hz
Max. Charging Current (NC)
12A
Mains Low Voltage Charge Facility
Available
Battery Boost Voltage
14.4V ±0.2V / Battery
Battery Float Voltage
13.7V ±0.2V / Battery
Mains Input Voltage
90V - 600V ±10V AC
Change Over Time(Mains to Back up)
40 msec
Change Over Time(Back up to Mains)
10 msec
Mains Input Voltage Range
180V - 270V ±10C AC
Rating Solar Charge Controller
12V 30A
Max. Charging Current By Solar
30A ±2A
Solar Input Range(Voc)
16V - 25V
Recommended Solar Input
450W
Efficiency Of Solar Charge Controller
95%
Charge Sharing Option
Available
Type of Solar Charge Controller
True Hybrid
Overload Retry
6 Auto Retries
Battery Retry
4 Auto Retries
Short Circuit Retry
Available
